English
10
SPECIFICATIONS
Power Tool
Model CJ10DL
No-Load Speed 0 – 2700 min
-
1
Stroke 13 mm
Capacity Wood: Depth 50 mm
Mild Steel Plate: Thickness 4 mm
Rechargeable battery BCL1015: Li-ion DC 10.8 V / 12 V Peak (1.5 Ah 3 cells)
Weight 1.2 kg
10. Do not use in a location where strong static
electricity generates.
11. If there is battery leakage, foul odor, heat
generated, discolored or deformed, or in any way
appears abnormal during use, recharging or
storage, immediately remove it from the equipment
or battery charger, and stop use.
CAUTION
1. If liquid leaking from the battery gets into your
eyes, do not rub your eyes and wash them well
with fresh clean water such as tap water and
contact a doctor immediately.
If left untreated, the liquid may cause eye-problems.
2. If liquid leaks onto your skin or clothes, wash well
with clean water such as tap water immediately.
There is a possibility that this can cause skin irritation.
3. If you find rust, foul odor, overheating, discolor,
deformation, and/or other irregularities when using
the battery for the first time, do not use and return
it to your supplier or vendor.
WARNING
If an electrically conductive foreign object enters the
terminals of the lithium ion battery, a short-circuit may
occur resulting in the risk of fire. Please observe the
following matters when storing the battery.
䡬 Do not place electrically conductive cuttings, nails,
steel wire, copper wire or other wire in the storage
case.
䡬 Either install the battery in the power tool or
store by securely pressing into the battery cover
until the ventilation holes are concealed to prevent
short-circuits (See Fig. 1).
Charger
Model UC10SFL
Charging voltage 10.8 V
Weight 0.35 kg
STANDARD ACCESSORIES
1 Blade (No. 41) ....................................... 1
CJ10DL
2 Blade (No. 123X) ................................... 1
(NN)
3 Hexagonal bar wrench ......................... 1
1 Blade (No. 41) ....................................... 1
2 Blade (No. 123X) ................................... 1
CJ10DL 3 Hexagonal bar wrench ......................... 1
(LCSK) 4 Battery (BCL1015) .................................. 1
5 Charger (UC10SFL) ................................ 1
6 Plastic case ............................................. 1
1 Blade (No. 41) ....................................... 1
2 Blade (No. 123X) ................................... 1
CJ10DL
3 Hexagonal bar wrench ......................... 1
4 Battery (BCL1015) .................................. 2
(2LCSK)
5 Charger (UC10SFL) ................................ 1
6 Plastic case ............................................. 1
7 Battery cover .......................................... 1
Standard accessories are subject to change without
notice.
OPTIONAL ACCESSORIES (sold separately)
1. Battery (BCL1015)
2. Blades
Various types of blades.
Refer to Table 2 for use of the blades.
Optional accessories are subject to change without
notice.
APPLICATIONS
䡬 Cutting various lumbers.
䡬 Cutting mild steel plates and aluminum plates.
䡬 Cutting synthetic resins, such as phenol resin and
vinyl chloride.
For details refer to the section entitled “SELECTION OF
BLADES”.
01Eng_CJ10DL_EE 7/24/09, 17:4610
