Hitachi CJ10DL [14/96] English

English

carry out pocket cutting quite easily with the saw

blade installed in reverse as illustrated in Fig. 23,

Fig. 25, and Fig. 27. Use the saw blade that is as

short and thick as possible.

(1) Press the lower part (or the upper part) of the base

against the material. Pull the switch trigger while

keeping the tip of the saw blade apart from the

material (Fig. 22, Fig. 23).

(2) Raise the handle slowly and cut in with the saw

blade little by little (Fig. 24, Fig. 25).

(3) Hold the body firmly until the saw blade completely

cuts into the material (Fig. 26, Fig. 27).

CAUTION

䡬 Avoid plunge cutting for metallic materials. This can

easily damage the blade.

䡬 Never pull the switch trigger while the tip of the

saw blade is pressed against the material. If you

do so, the blade can easily be damaged when it

collides with the material.

䡬 Make absolutely sure that you cut slowly while

holding the body firmly. If you apply any

unreasonable force to the saw blade during the

cutting operation, the blade can easily be damaged.

NOTE

The use of the battery BCL1015 in a cold condition

(below 0 degree Centigrade) can sometimes result

in the weakened cutting torque and reduced amount

of work. This, however, is a temporary phenomenon,

and returns to normal when the battery warms up.

6. Battery Level Warning Lamp

The battery level can be checked by pulling the

trigger switch while the power tool is in a no-load

state. The battery level warning lamp lights when

the battery power is very low. If this happens,

charge the battery. (Fig. 5)

NOTE

䡬 The level at which the battery level warning lamp

lights may vary due to the ambient temperature,

characteristics of the battery, etc. and is intended

only as a guide.

䡬 The battery level warning lamp may light when the

power tool is overloaded. This does not mean that

the battery power is very low.

Be sure to check the battery level while the tool

is in a no-load state.

01Eng_CJ10DL_EE 7/24/09, 17:4613
