Hitachi CJ10DL [12/96] English

English

If you continue to use the tool and exhaust the

electric current, the battery may be damaged and

its life will become shorter.

(2) Avoid recharging at high temperatures.

A rechargeable battery will be hot immediately after

use. If such a battery is recharged immediately after

use, its internal chemical substance will deteriorate,

and the battery life will be shortened. Leave the

battery and recharge it after it has cooled for a

while.

CAUTION

䡬 When the battery charger has been continuously

used, the battery charger will be heated, thus

constituting the cause of the failures. Once the

charging has been completed, give 15 minutes rest

until the next charging.

䡬 If the battery charger does not work while the

battery is mounted correctly, it is probable that the

battery or charger is malfunctioning. Take it to your

authorized Service Center.

PRIOR TO OPERATION

1. Mounting the blade

This unit employs a detachable mechanism that

enables mounting and removal of saw blades

without the use of a wrench or other tools.

(1) Turn on and off the switching trigger several times

so that the lever can jump out of the housing

completely (Fig. 6). Thereafter, turn off the switch

and remove the battery.

CAUTION

Be absolutely sure to keep the switch turned off

and the battery removed to prevent any accident.

(2) Push the lever in the direction of the arrow mark

shown in Fig. 7 marked on the lever (Fig. 7).

(3) Insert the saw blade all the way into the small slit

of the plunger tip with the lever pushing. You can

mount this blade either in the upward or downward

direction (Fig. 8, Fig. 9).

(4) When you release the lever, the spring force will

return the lever to the correct position automatically

(Fig. 10).

(5) Pull the back of the saw blade two or three times

by hand and check that the blade is securely

mounted (Fig. 11).

CAUTION

When pulling the saw blade, be absolutely sure to

pull it from the back. Pulling other parts of the blade

will result in an injury.

2. Dismounting the blade

(1) Turn on and off the switching trigger several times

so that the lever can jump out of the housing

completely (Fig. 6). Thereafter, turn off the switch

and remove the battery.

CAUTION

Be absolutely sure to keep the switch turned off

and the battery removed to prevent any accident.

(2) After you have pushed the lever in the direction

of the arrow mark shown in Fig. 7 and secured it,

move the saw blade towards the lever and pull it

out (Fig. 12).

CAUTION

Never touch the saw blade immediately after use.

The metal is hot and can easily burn your skin.

BATTERY REMOVAL/INSTALLATION

CAUTION

Be sure to keep the switch turned off and the lock-

off button moved to right position (lock position)

(See Fig. 17).

1. Battery removal

Hold the housing tightly and push the battery latches

to remove the battery (see Figs. 1 and 2).

CAUTION

Never short-circuit the battery.

2. Battery installation

Insert the battery while observing its polarities (see

Fig. 2).

CHARGING

Before using the power tool, charge the battery as

follows.

1. Connect the charger power cord to the receptacle

2. Insert the battery in the charger

Position the battery so that the nameplate faces

toward the nameplate of the charger and press in

the battery until it comes into contact with the

bottom plate (See Fig. 3).

Inserting the battery will turn on the charger (the

pilot lamp lights up).

CAUTION

If the pilot lamp does not light up, pull out the

power cord from the receptacle and check the

battery mounting condition.

The pilot lamp goes off to indicate that the battery

is fully charged.

CAUTION

If the battery is heated due to direct sunlight,

etc., just after operation, the charger pilot lamp

may not light. At that time cool the battery first,

then start charging.

䡬 Regarding recharging time

Table 1 shows the recharging time required

according to the type of battery.

NOTE: The recharging time may vary according to the

ambient temperature.

3. Disconnect the charger’s power cord from the

receptacle.

4. Hold the charger firmly and pull out the battery.

NOTE

Be sure to pull out the battery from the charger

after use, and then keep it.

How to make the batteries perform longer

(1) Recharge the batteries before they become

completely exhausted.

When you feel that the power of the tool becomes

weaker, stop using the tool and recharge its battery.

Table 1 Recharging time (approx. min.) at 20°C

Battery capacity (Ah)

1.5 Ah

BCL1015 40 min.

01Eng_CJ10DL_EE 7/24/09, 17:4611
