MAINTENANCE AND INSPECTION OF SAW BLADE

MOUNT

(1) After use, blow away sawdust, earth, sand, moisture,

etc., with air or brush them away with a brush, etc.,

to ensure that the blade mount can function

smoothly.

(2) As shown in Fig. 13, carry out lubrication around

the blade holder on a periodic basis by use of

cutting fluid, etc.

NOTE

Continued use of the tool without cleaning and

lubricating the area where the saw blade is installed

can result in some slack movement of the lever due

to accumulated sawdust and chips. Under the

circumstances, pull a rubber cap provided on the

lever in the direction of an arrow mark as shown

in Fig. 14 and remove the rubber cap from the lever.

Then, clean up the inside of the blade holder with

air and the like and carry out sufficient lubrication.

The rubber cap can be fitted on if it is pressed firmly

onto the lever. At this time, make certain that there

exists no clearance between the blade holder and

the rubber cap, and furthermore ensure that the

saw-blade-installed area can function smoothly.

3. Moving the base

Loosen the hex. socket bolt with hexagonal bar

wrench and move the base forward, as shown in

Fig. 15, Fig. 16. Tighten the set screw slightly,

ensure the base does not move back and forth, and

firmly tighten the hex. socket bolt. Ensure that the

base does not contact the blade.

4. Confirm that the battery is mounted correctly

HOW TO USE

How to make the batteries perform longer

䡬 Recharge the batteries before they become

completely exhausted.

When you feel that the power of the tool becomes

weaker, stop using the tool and recharge its battery.

If you continue to use the tool and exhaust the

electric current, the battery may be damaged and

its life will become shorter.

CAUTION

䡬 Do not carry tools with your finger on the switch.

A sudden startup can result in an unexpected injury.

䡬 Be careful not to let sawdust, earth, moisture, etc.,

enter the inside of the machine through the plunger

section during operation. If sawdust and the like

accumulate in the plunger section, always clean it

before use (refer to Fig. 6).

䡬 During use, press the base against the material

while cutting.

Vibration can damage the saw blade if the base is

not pressed firmly against the workpiece.

Furthermore, a tip of the saw blade can sometimes

contact the inner wall of the workpiece, damaging

the saw blade.

䡬 Select a saw blade of the most appropriate length.

Ideally, the length protruding from the base of the

saw blade after subtracting the stroke quantity should

be larger than the material (see Fig. 18).

If you cut a large block of wood, etc., that exceeds

the cutting capacity of a blade; there is a risk that

the blade may contact with the inner wall of the

wood, etc., resulting in damage (Fig. 19).

䡬 To extend the lifetime, the lithium-ion battery equips

with the protection function to stop the output.

Therefore, if the tool is overloaded, the motor may

stop. However, this is not the trouble but the result

of protection function. In this case, release the switch

of tool and eliminate the causes of overloading.

1. Switch operation

(1) Lock-off button

The tool is equipped with a lock-off button. To

activate the trigger lock, move the button to the

right position. Move the button to the left to operate

the tool (Fig. 17).

Always lock the switch when carrying or storing the

tool eliminate unintentional starting.

(2) Trigger switch

This tool is equipped with a variable speed controlled

trigger switch. The tool can be turned "ON" or "OFF"

by squeezing or releasing the trigger. The blade

plunger stroke rate can be adjusted from the

minimum to maximum nameplate stroke rate by

the pressure you apply to the trigger. Apply more

pressure to increase the speed and release pressure

to decrease speed.

2. Using the light

Pull the trigger switch to light up the light. The light

keeps on lighting while the trigger switch is being

pulled. The light goes out after releasing the trigger

switch. (Fig. 4)

CAUTION

Do not look directly into the light. Such actions

could result in eye injury.

3. Cutting lumber

When cutting lumber, make sure that the workpiece

is fastened firmly before beginning (Fig. 20).

CAUTION

䡬 Never apply any unreasonable force to the saw

blade when cutting. Also remember to press the

base against the lumber firmly.

䡬 Delay the feed speed when cutting the material into

small circular arcs. An unreasonably fast feed may

break the blade.

4. Cutting metallic materials

CAUTION

䡬 Press the base firmly against the workpiece.

䡬 Never apply any unreasonable force to the saw

blade when cutting. Doing so can easily break the

blade.

䡬 The motor can be locked sometimes, depending on

the combination of the material to be cut and the

blade. Whenever the motor gets locked, switch it

off immediately.

(1) Fasten a workpiece firmly before operation (Fig. 21).

(2) When cutting metallic materials, use proper machine

oil (turbine oil, etc.). When not using liquid machine

oil, apply grease over the workpiece.

CAUTION

The service life of the saw blade will be drastically

shortened if you don’t use machine oil.

5. Plunge cutting

With this tool, you can perform plunge cutting on

plywood panels and thin board materials. You can

01Eng_CJ10DL_EE 7/24/09, 17:4612
