Citizen CL-E720DT [133/154] Rs 232c serial interface

1-132

5.1 RS-232C Serial Interface

1 Specifications

Transmission system: Asynchronous communication method (full duplex)

Signal logic level: RS-232C

Baud rate: 2400, 4800, 9600, 14400, 19200,

38400, 57600, 115200 bps

Data length: 7 bits or 8 bits

Start bit: 1 bit

Stop bit: 1bit, 2bits

Parity check: Odd parity, even parity, none

Connector: D-sub 25pin 17LE-13250-27(D41)(DDK) or

equivalent

2 Example of connection of computer and printer

IBM compatible machines

Communication control: XON/XOFF or CTS/DTR

"IBM compatible"

(DB9P) (DB25P)

SHILED

TXD

RXD

CTS

S.GND

1 F.GND

3 RXD

2 TXD

20 DTR

7 S.GN

DTR

DSR

4 RTS

5 CTS

Printer
