1-57
Completion of setting printing contents (field preparation) and printing labels
Code
E
Function
Completes printing contents setting and prints labels. On completion
of printing, command interpreter is switched to system level interpreter
and system level commands are valid.
Caution
If label format commands are used again, use the system level "STX"
+ "L" command.
Entering previous-defined field character string into global table
Code
G
Function
Enters a previous-defined label format character string into global
table, allocating one character in alphabetical order from A to P.
Reading of character string stored in the global table is executed with
command "
Reading out from global register "
Example
Input data below represents that data of character string "ABC" is
stored in the global table with font 9 and fonts 9 and 5 are printed.
Input data
[02] n Sets units to inch
[02] L Starts label format mode
D22 Sets pixel size
190000500800120ABC Sets character data "ABC" with
smooth font 14pt
G Stores character string "ABC" in
global table
151100002800120[02]SA
E Ends label format mode and prints
Setting print density (head heat factor)
Code
H nn
Setting
nn 00 – 20 in DPP
00 – 30 in DM4/DM8/DMI/DMW
Initialization value: 10
Function
Sets print density (heat energy is applied to print head).
