Command Reference DMX Страница: 68

Citizen CL-E720DT [68/154] Specifying ending code

1-67

Specifying ending code

Code

T nn

Setting

nn Two characters of hex ASCII code

Initialization value: CR[0D]

Function

Specifies ending code, which is valid for field immediately after this

command and after that field ending returns to default CR [0D].

Example

The following shows that ending code uses NULL [00].

Input data

[02] n Sets units to inch

[02] L [0D] Starts label format mode

D22 Sets pixel size

T00 [0D] Sets ending code to 'NULL [00]'

190000500800120ABC [00] Sets character data "ABC" with

smooth font 14pt

Q0002 [0D] Sets 2-sheet-printing

E Ends label format mode and prints
