![Citizen CL-E720DT [82/154] Table 3](/views2/1842788/page82/bg52.png)
1-81
Table 3
Font Bar code name Bar ratio (thick:narrow) No. of valid data
A Code 3 of 9 3:1 Variable length
B UPC-A 1:1, 2:2, 3:3, 4:4, 6:6, 8:8 12
C UPC-E 1:1, 2:2, 3:3, 4:4, 6:6, 8:8 8
D Interleaved 2 of 5 5:2 Even digit
variable length
E Code 128 Variable length
F EAN-13 (JAN-13) 1:1, 2:2, 3:3, 4:4, 6:6, 8:8 13
G EAN-8 (JAN-8) 1:1, 2:2, 3:3, 4:4, 6:6, 8:8 8
H HIBC
(Modulus 43-used Code 3 of 9)
3:1 Variable length
I CODERBAR (NW-7) 3:1 Variable length
J Int 2 of 5
(Modulus 10-used Interleaved 2 of
5)
5:2 Odd digit
variable length
K Plessey Variable length
L CASE CODE 5:2 14
M UPC 2DIG ADD
(UPC 2-digit supplementary code)
3
N UPC 5DIG ADD
(UPC 5-digit supplementary code)
6
O Code 93 1:1, 2:2, 3:3, 4:4, 6:6, 8:8 Variable length
p ZIP Variable length
Q UCC/EAN128 1:1, 2:2, 3:3, 4:4, 6:6, 8:8 19*
R UCC/EAN128 (for K-MART) 1:1, 2:2, 3:3, 4:4, 6:6, 8:8 18*
S UCC/EAN128 Random Weight 1:1, 2:2, 3:3, 4:4, 6:6, 8:8 34 or more*
T Telepen Variable length*
U / u UPS MaxiCode 84 or less*
v FIM 1*
Z / z PDF417 Variable length
W1C/W1c DataMatrix Variable length
W1D/W1d QR CODE Variable length
W1F/W1f Aztec Variable length
ESC
Head of character
string
＝
q
QR CODE
Variable length
Head of character
string=M
Matrix 2 of 5
5:2 Variable length
