1-51
1.6.3 Label Format Commands
The following commands will be valid if the label format command
interpreter is turned on with "STX" + "L," i.e. [02] L.
Set format attribute A
Set format attribute [1B]B
Setting offset in direction of column C
Setting number of cuts (2-digit) c
Setting pixel size in horizontal and vertical direction D
Completion of setting printing contents (field preparation) and
printing labels
E
Entering previous-defined field character string into global table G
Setting print density (head heat factor) H
Changing units from inch to metric system m
Changing units from metric to inch system n
Setting printable area speed P
Setting backfeed speed p
Specifying space between characters [1B]P
Setting number of prints Q
Setting offset in direction of row R
Calling label format r
Setting unprintable area speed S
Storing label format s
Specifying ending code T
Setting previous field to character-string-replacement-mode
field
U
Completion of setting printing contents (field preparation) X
TrueType font symbol setting y
Setting slash zero z
Setting addition of previous-defined printing contents (field
data) 1
+
Setting subtraction of previous-defined printing contents (field
data) 1
-
Setting addition of previous-defined printing contents (field
data) 2
>
Setting subtraction of previous-defined printing contents (field
data) 2
<
