1-139
Appendix 1 List of Commands
Y : Supported command
N/A: Not supported command
System level commands Models
521
621
9001
9301
8301
SOH # Reset Y Y
A Printer status transmission request (8 bytes) Y Y
B Pause Y Y
C Stop/cancel Y Y
D Stop immediate execution of system level
commands
Y Y
E Transmission of number of remaining prints Y Y
F Printer status transmission request [1 byte] Y Y
|
Error status transmission request [4-byte]
Y Y
STX
A Setting date and time [transmission]
N/A Y
a Feedback character transmission validness
Y Y
B Date and time transmission request
N/A Y
cnnnn Setting continuous paper length
Y Y
d Setting 2-page edit mode (double buffer)
Y Y
Ennnn Setting number of printing sheets for edited
format
Y Y
e Selecting edge sensor for paper position
detection
Y Y
F Label one sheet feed
Y Y
fnnn Setting paper position setting when cutting
and peeling
Y Y
G Printing edited format
Y Y
Imfaa Writing graphic data
Y Y
imTnn TrueType fonts downloading command
Y Y
J Setting pause per each label printing
Y Y
KDabc printer settings
Y N/A
Kfnnnn Setting paper position setting when cutting and
peeling
Y Y
k "Y" code transmission request Y Y
L Starting printing contents setting (label format) Y Y
(continued)
