1-72
Setting addition of previous-defined printing contents (field data) 2
Code
> pii..
Setting
p Specifies character (all ASCII characters available) for filling zero.
ii Amount of addition (use of ASCII characters of A - Z prohibited)
Function
Adds field data which was defined before this command by using base
36 system of 0 - 9, A - Z.
Example
Input data below represents that data "1000" is printed 5 sheets by
using this command specifying 5 for the amount of addition.
Input data
[02] n Sets units to inch
[02] L Starts label format mode
D11 Sets pixel size
1900010000000500001 Sets data "0001" with smooth font 48pt
>05 Amount of addition: +5
Q0005 Specifies 5-sheet-printing
E Ends label format mode and prints
Direction of feed
000G
000L
0006
000B
0001
5th sheet
2nd sheet
3rd sheet
4th sheet
1st sheet
In case of addition “>05”
L
G
B
6
1
In case of addition “> 5”
5th sheet
2nd sheet
3rd sheet
4th sheet
1st sheet
