1-79
Type Font Character field definition
Code
rotate, font, hexp, vexp, id, row, column, height, width, d1, d2,.......
Setting
rotate Sets rotation direction for character data 1, 2, 3, 4
1: 0 º 2: 90 º 3: 180 º 4: 270 º
font 9 fixed
hexp Sets expansion rate in horizontal direction 1 - 9, A - O
(A - O corresponding to 10 - 24)
vexp Sets expansion rate in vertical direction 1 - 9, A – O
(A - O corresponding to 10 - 24)
id Download font ID Refer to table 2.
row Row address 0000 - 9999 Unit: 0.01 inch
column Column address 0000 - 0410 Unit: 0.01 inch
height Sets character height by a code of “P”+3 characters
Number of dots set by unit of a dot.
Width Sets character width by a code of “P”+3 characters
Number of dots set by unit of a dot.
d1, d2,.. character data followed by “CR” code to end
Function
Downloaded TrueType font is printed in the print mode specified by
this command.
Example
Print the characters, “TrueType”, in TrueType font (ID=54) with 24 pt
height and width.
Input data
[02] n Sets units to inch
[02] L Starts label format mode
D11 Sets pixel size
ySUK Sets symbol set for UK.
19 11 S54 0100 0100 P024 P024 TrueType
E Ends label format mode and
prints
