Citizen CL-E720DT [78/154] Table 1 a 203 dpi print head
![Citizen CL-E720DT [78/154] Table 1 a 203 dpi print head](/views2/1842788/page78/bg4e.png)
1-77
Table 1-A ( 203 dpi print head )
Dot number Pixel size horizontal (H) x vertical (V) Units (mm)
Type of
character
Font H Space V 1 x 1 2 x 2 2 x 3
3 x 2
*1
System font 0 5 1 7 0.8 x 0.9 1.5 x 1.8 1.5 x 2.6 2.3 x 1.8
1 7 2 13 1.1 x 1.6 2.3 x 3.3 2.3 x 4.9 3.4 x 3.3
2 10 2 18 1.5 x 2.3 3.0 x 4.5 3.0 x 6.8 4.5 x 4.5
3 14 2 27 2.0 x 3.4 4.0 x 6.8 4.0 x 10.1 6.0 x 6.8
4 18 3 36 2.6 x 4.5 5.3 x 9.0 5.3 x 13.5 7.9 x 9.0
5 18 3 52 2.6 x 6.5 5.3 x 13.0 5.3 x 19.5 7.9 x 13.0
6 32 4 64 4.6 x 8.0 9.0 x 16.0 9.0 x 24.0 13.5 x 16.0
7 15 5 32 2.5 x 4.0 5.0 x 8.0 5.0 x 12.0 7.5 x 8.0
8 15 5 28 2.5 x 3.5 5.0 x 7.0 5.0 x 10.5 7.5 x 7.0
Table 1-B ( 300 dpi print head )
Dot number Pixel size horizontal (H) x vertical (V) Units (mm)
Type of
character
Font H Space V 1 x 1 2 x 2 2 x 3
3 x 2
*1
System font 0 6 1 10 0.6 x 0.8 1.2 x 1.7 1.2 x 2.5 1.8 x 1.7
1 10 3 18 1.1 x 1.5 2.2 x 3.0 2.2 x 4.6 3.3 x 3.0
2 14 3 27 1.4 x 4.8 2.9 x 9.7 2.9 x 14.5 4.3 x 9.7
3 18 3 36 1.8 x 3.0 3.6 x 6.1 3.6 x 9.1 5.3 x 6.1
4 24 4 48 2.4 x 4.1 4.7 x 8.1 4.7 x 12.2 7.1 x 8.1
5 24 4 72 2.4 x 6.1 4.7 x 12.2 4.7 x 18.3 7.1 x 12.2
6 42 6 88 4.1 x 7.5 8.1 x 14.9 8.1 x 22.4 12.2 x 14.9
7 22 7 46 2.5 x 2.7 4.9 x 5.4 4.9 x 8.1 7.4 x 5.4
8 21 8 33 2.5 x 2.7 4.9 x 5.4 4.9 x 8.1 7.4 x 5.4
Note: *1 represents that character rotation direction is 90 and 270 deg.
A
B
Horizontal (H)
Vertical (V)
