1-27
Download of TrueType Font
Code
[02] i m T nn name <CR> xxxxxxxx data…
Transmission
data
m Storing memory module specification
Allocation of modules varies with command settings. Refer to
the table below.
Command Set
Allocation of module DMI / DMW DM4 / DM8 DPP
on-board SD-RAM D A B
on-board flash memory G B A
PCMCIA Card (option) E or F E or F E or F
Current memory module on-board
SD-RAM
on-board
SD-RAM
on-board
SD-RAM
T T fixed (TrueType)
nn Two-digit font ID
Valid values: 50 – 59, 5A – 5Z, 5a – 5z,
60 – 69, 6A – 6Z, 6a – 6z,
:
90 –99, 9A – 9Z, 9a – 9z
name Font name (Max. 16 characters followed by CR code to end)
xxxxxxxx TrueType font data size, number of bytes assigned by 8
digits hexadecimal characters.
data TrueType font data
Function
Stores specified font data in the specified memory module.
Caution
File will be overwritten when the font data is stored in the memory
module using the same name of the existing file. Therefore, free
space for the file to write new data will be necessary.
Example
The following command line shows the command to download 34754
bytes of TrueType font file, named “Tree Frog”, with the font ID 52 into
the memory module B:
Input data
[02] iCT52TreeFrog<CR>000087C2 data…
