![Citizen CL-E720DT [47/154] Truetype font symbol set selection](/img/pdf.png)
Citizen CL-E720DT [47/154] Truetype font symbol set selection
![Citizen CL-E720DT [47/154] Truetype font symbol set selection](/views2/1842788/page47/bg2f.png)
1-46
TrueType font symbol set selection
Code
[02] ySxx
Setting
S S fixed
xx Specification of a symbol set
The character sequence of 2 figures
(Refer to the following table for a setting value.)
Function
Selection of a TrueType font symbol set
Caution
It depends on each TrueType font file for the symbol set which
becomes actually effective.
Example
PC-850 multilingual is chosen.
Input data
[02] ySPM
Table
XX Font name XX Font name
US ISO 6: ASCII (standard) PE PC-852 Latin 2
DN ISO 60: Danish/Norwegian W1 Windows 3.1 Latin 1
IT ISO 15: Italian PD PC-8 D/N, Code Page 437N
GR ISO 21: German PC PC-8 Code Page 437
FR ISO 69: French MC Macintosh
E5 ISO 8859/5 Latin 5 SW ISO 11: Swedish
E2 ISO 8859/2 Latin 2 SP ISO 17: Spanish
E1 ISO 8859/1 Latin 1 UK ISO 4: United Kingdom
DT DeskTop TS PS Text
LG Legal WE Windows 3.1 Latin 2
R8 Roman-8 WO Windows 3.0 Latin 1
PT PC-8 TK, Code Page 437T PI PI font
PM PC-850 Multilingual
WT Windows 3.1 Latin 5
