RCMMS User Manual
2
Features
Single sign-on to consolidate the management of all ATEN RCM devices
Device and Panel Array Grouping for easy, convenient management
Customizable Panel Array layout for up to 25 (5x5) simultaneous port
monitoring
Instantaneous remote access to RCM device ports via WinClient viewer
RPA (robotic process automation) scripting and automated processing of
various conditions and actions
Flexible image setting for various, all-encompassing applications
Account authentication via AD/LDAP server
Event notification and Access Control Box pushbutton alert
Requirements
Server Requirements
Systems that the RCMMS server will be installed on should meet the following
requirements:
PC Requirements
Licenses
The RCMMS license controls the total number of KVM ports permitted on the
installation, which must be purchased from and activated by your local dealer.
Recommended Minimum
CPU Intel Core i5 3+ GHz or above Intel Core i3 2+ GHz or above
OS Windows 7 / 10
Memory 4 GB or above
Hard Drive 32 GB or above (with the program taking up 250 ~ 300 MB)
Ethernet At least 1 Ethernet adapter (100 Mbps or above)
— Giga LAN recommended
