![Aten RCMMS [59/73] Click cancel to abandon your changes and close the dialog box](/views2/1977515/page59/bg3b.png)
Chapter 8. The WinClient Viewer
51
Click OK to save your changes and close the dialog box.
Click Cancel to abandon your changes and close the dialog box.
Enable Refresh
The RCMMS can redraw the screen every 1 to 99 seconds,
eliminating unwanted artifacts from the screen. Select Enable
Refresh and enter a number from 1 through 99. The RCMMS will
redraw the screen at the interval you specify. This feature is
disabled by default. Click to put a check mark in the box next to
Enable Refresh to enable this feature.
Note: 1. The switch starts counting the time interval when
mouse movement stops.
2. Enabling this feature increases the volume of video
data transmitted over the network. The lower the
number specified, the more often the video data is
transmitted. Setting too low a value may adversely
affect overall operating responsiveness.
Transparency Adjusts the transparency of the toolbar that comes up when the
GUI hotkey ([Scroll Lock][Scroll Lock], for example) is invoked.
Slide the bar until the display in the example window is to your
liking.
Color Depth Control This setting determines the richness of the video display by
adjusting the amount of color information.
Detect Tolerance This setting also relates to video quality. It governs detecting or
ignoring pixel changes. A high setting can result in a lower quality
display due to less data transfer. A lower setting will result in
better video quality, but setting the threshold too low may allow
too much data to be transferred, negatively impacting network
performance.
Option Usage
