Chapter 4. Script
17
Script Editor
The interface of the Script Editor and its components are described below.
No. Item Description
A Tool Box Contains the following tools:
Select: Adds or moves components into or within
the interactive script by dragging and dropping.
Flow: Links components within the interactive
script by selecting, dragging, and releasing.
Delete: Deletes component selected within the
interactive script.
B Component
Library
Lists the types of components available that can be added
into the interactive script by dragging and dropping.
C Interactive Script Displays the components and flows the script currently
contains.
D Component
Properties
Displays and edits the properties of the component
currently selected, within the interactive script.
1 Script Info Displays and edits the name and description of the script.
2 Test Script Executes and tests the script as currently configured.
3 Display Size Adjusts the display size of the interactive script.
A
C
1
2
B
D
3
