Chapter 8. The WinClient Viewer
61
Mouse DynaSync Mode
Clicking this icon selects whether synchronization of the local and
remote mouse pointers is accomplished either automatically or
manually.
Automatic Mouse Synchronization (DynaSync)
Mouse DynaSync provides automatic locked-in synching of the remote and
local mouse pointers – eliminating the need to constantly resync the two
movements.
The icon on the toolbar indicates the synchronization mode status as follows:
When Mouse DynaSync is available, clicking the icon toggles between enabled
and disabled. If you choose to disable Mouse DynaSync mode, you must use
the manual syncing procedures described in the next section.
Manual Mouse Synchronization
If you are using Manual mouse synchronization instead of automatic
DynaSync and the local mouse pointer goes out of sync with the remote
system's mouse pointer, there are a number of methods to bring them back into
sync:
1. Perform a video and mouse auto sync by clicking the Video Settings icon
on the Control Panel (see page 49).
2. Perform an Auto Sync with the Video Adjustment function (see Video
Settings, page 49, for details).
3. Invoke the Adjust Mouse function with the Adjust Mouse hotkeys (see
Adjust mouse, page 42, for details).
4. Move the pointer into all 4 corners of the screen (in any order).
5. Drag the Control Panel to a different position on the screen.
6. Set the mouse speed and acceleration for each problematic computer
attached to the switch. See the RCM device user manual for details.
Icon Function
This icon indicates that Mouse DynaSync is available and is
enabled. This is the default setting when Mouse DynaSync is
available.
The / over this icon indicates that Mouse DynaSync is available but
is not enabled.
