Chapter 8. The WinClient Viewer
55
Virtual Media
The Virtual Media feature allows a drive, folder, image file, or
removable disk on a local client computer to appear and act as if it were
installed on the remote server. Virtual Media also supports a smart card reader
function that allows a reader plugged into a local client computer to appear as
if it were plugged into the remote server.
Virtual Media Icons
The Virtual Media icon on the Control Panel changes to indicate whether the
virtual media function is available, or if a virtual media device has already been
mounted on the remote server, as shown in the table below
Virtual Media Redirection
To implement the virtual media redirection feature, do the following:
1. Click the Virtual Media icon to bring up the Virtual Media dialog box:
Icon Function
The icon displays in gray to indicate that the virtual media function is
disabled or not available.
The icon displays in blue to indicate that the virtual media function is
available. Click the icon to bring up the virtual media dialog box.
The icon displays in blue with a / to indicate that a virtual media
device has been mounted on the remote server. Click the icon to un-
mount all redirected devices.
