RCMMS User Manual
20
Script Components
Below is a list of the components, conditions and actions, that can be added into
the RPA scripts.
Type Item Description
Start and
End
Start Indicates the start of the RPA script.
End Indicates the end of the RPA script.
Condition Match Text Defines a text string and uses OCR to check if it
matches with the server’s display info.
Match Number Defines a number property and uses OCR to check if it
matches with the server’s display info.
Match Picture Selects a *.bmp image and checks if it matches with
the server’s display info.
Match Color Defines a color code and checks if it matches with the
server’s display info.
Get Control Box
Pushbutton
Gets the pushbutton status from a connected ATEN
Access Control Box.
TCP Receiver Sets a TCP receiver channel to get a set of data from a
TCP client that matches with the response set, either
exactly or partially.
Note: To modify the TCP port value, see Logs,
page 32.
Action Color Highlight
on Panel Array
Highlights the server with the color set, and optionally
indicated as a warning.
Popup Dialog Triggers a popup dialog with the contents defined.
Popup WinClient Triggers a WinClient window.
Send Keyboard /
Mouse
Sends the keyboard and mouse operations defined.
Set Mouse Mode Sets the mouse to either auto or manual mode.
Set Access Type Sets the access privilege of the server.
Delay Sets a delay of up to 3600 seconds.
Command Line Executes the command defined.
Set OSD
Message
Defines an OSD message on the position set, either
locally or remotely.
Send Mail Sends an email via SMTP.
Note: To set the SMTP server settings, see SMTP
Settings, page 31.
Save OCR Text Sets the text mode and output path for the OCR text to
be saved.
