RCMMS User Manual
38
Control Panel Functions
The Control Panel functions are described in the table below.
Icon Function
Toggles to always display the Control Panel or only display it when
the mouse hovers over it.
Click to bring up the Macros dialog box. (See Video Settings,
page 49, for details).
Click to bring up the Video Options dialog box. Right-click to perform
a quick Auto Sync (see Video Settings, page 49, for details).
Performs video and mouse autosync. It is the same as clicking the
Auto-sync button in the Video Options dialog box (see Video
Settings, page 49).
Toggles the display between Full Screen and Windowed Mode.
Takes a snapshot (screen capture) of the remote display. To
configure the Snapshot parameters, refer to Snapshot on page 63.
Brings up the Message Board (see The Message Board, page 53).
