Chapter 8. The WinClient Viewer
39
Sends a [Ctrl] + [Alt] + [Del] signal to the remote system.
Toggles the remote display between color and grayscale.
Brings up the Virtual Media dialog box. The icon changes when a
virtual media device is mounted on the port. See Virtual Media,
page 55, for specific details.
Note: This icon is displayed in gray when the function is disabled or
not available to the user.
Click to zoom the remote display window.
Note: This feature is only available in windowed mode (Full Screen
Mode is off). See Zoom, page 58, for details.
Brings up the on-screen keyboard (see The On-Screen Keyboard,
page 59).
Selects the mouse pointer type.
Note: This icon changes depending on which mouse pointer type is
selected (see Mouse Pointer Type, page 60).
Toggles between Automatic or Manual mouse sync.
When the selection is Automatic, a green mark appears on the
icon.
When the selection is Manual, an
/
appears over the icon.
See Mouse DynaSync Mode, page 61.
Displays a drop-down Macro List of User macros (see Macros,
page 41 for details).
Accesses a viewer-based GUI for device configuration(see Open
GUI, page 64).
Brings up the Customize Control Panel dialog box (see Control
Panel Configuration on page 62, for details).
Exits the Viewer and goes back to RCMMS.
Icon Function
