RCMMS User Manual
26
Once all of the required fields of each new user have been entered, save and
import the User List into the RCMMS to add.
AD/LDAP Settings
For the user accounts of RCMMS to be authenticated via AD/LDAP, click
> User > AD/LDAP Settings. The following dialog box appears.
Enter the required information, as explained below.
Host Domain: The IP address or URL of the AD/LDAP server.
Port: The port through which RCMMS communicates with the AD/LDAP
server.
The user info will be created automatically as the user login by AD
successfully: Check or uncheck to enable or disable this function.
Single Sign-On: Check or uncheck to enable or disable this function.
Click Save for changes to take effect.
AD Account Password Username
Define the
verification type, 0 =
Local; 1 = AD.
Define the login
name of the user
account.
Define the login
password of the
user account.
Type the display
name of the
account.
