RCMMS User Manual

Auto-Sync Click Auto-Sync to have the vertical and horizontal offset values

of the remote screen detected and automatically synchronized

with the local screen.

Note: 1. If the local and remote mouse pointers are out of sync,

in most cases, performing this function will bring them

back into sync.

2. This function works best with a bright screen.

3. If you are not satisfied with the results, use the Screen

Position arrows to position the remote display manually.

RGB Drag the slider bars to adjust the RGB (Red, Green, Blue)

values. When an RGB value is increased, the RGB component of

the image is correspondingly increased.

If you enable Set to Grayscale, the remote video display is

changed to grayscale.

Gamma This section allows you to adjust the video display's gamma

level.

If default gamma level is not ideal, you can click the drop-down

menu for a list of preset gamma levels and select from it. There

are ten preset and four user-defined levels to choose from. To

define the user-defined levels, click the Advanced button. This

function is discussed in detail in the next section.

Performance Select the type of Internet connection that exists between the

Local Client computer and the RCM device. The RCM device will

use that selection to automatically adjust the Video Quality and

Detect Tolerance settings to optimize the quality of the video

display.

Since network conditions vary, if none of the pre-set choices

seem to work well, you can select Customize and use the Video

Quality and Detect Tolerance slider bars to adjust the settings

to suit your conditions.

Video Quality Drag the slider bar to adjust the overall Video Quality. The larger

the value, the clearer the picture and the more video data goes

through the network. Depending on the network bandwidth, a

high value may adversely effect response time.

Option Usage
