Chapter 4. ATEN Configurator (VK6000)
127
Configuring the Control Interface (Viewer)
This section provides information on how to configure a control interface, the
viewer, for your control system and the functions of different control objects.
Getting Started with Configuring Viewers
Step Action Refer to
1. Understand the usages of Pages and
Subpages.
The Design Tab, page 128
2. Plan and consider the following
before creating the viewer:
required control actions and
suitable control elements
placement of these control
elements among Pages, and on
Subpages if needed
Control Object Properties,
page 147
Viewer List, page 129
3. Create a viewer. Adding Viewers, page 133
4. Based on your planning, add the
required Pages / Subpages.
Adding / Removing a Page,
page 138
Configuring a Subpage,
page 139
5. Add and configure control objects on
the created Pages / Subpages.
Configuring Control Objects,
page 144
