ATEN Control System User Manual
10
Requirements
Prepare the following equipment and make sure your equipment meets the
minimum requirements specified below.
Hardware devices to be controlled by your ATEN controller
Bidirectional RS-232/422/485 serial devices
One-way IR or serial transmitter hardware devices (for Control Box
only)
Relay hardware devices
Digital input hardware devices (for VK1200 / VK2100 / VK2200 and
Control Pad only)
Digital output hardware devices (for VK1200 / VK2100 / VK2200
only)
Ethernet-controlled PJLink, Telnet, ONVIF, TCP, UDP, HTTP, or
HTTPS devices
KNX-interface IP devices
Cables
One Cat 5e/6 Ethernet cable for connecting to the local area network
(Optional) Standard straight-through cables for serial devices with
DB9 connectors
A computer for configuring your ATEN Control System
Make sure the computer runs Windows 7, 8, 8.1 or 10
Make sure to install .NET Framework version 4.5 or later on the
computer before using the ATEN Database Generator
(Optional) Up to 10, 16 or 32 mobile devices for remote control,
respectively for Control Pad, VK1100 / VK2100, or VK1200 / VK2200
Note: A license is required for each mobile device. For detailed
information, see Licenses for Mobile Control, page 84.
