ATEN Control System User Manual
xxi
Conventions
This manual uses the following conventions:
Terminology
Monospaced Indicates text that you should key in.
[ ] Indicates keys you should press. For example, [Enter] means to
press the Enter key. If keys need to be chorded, they appear
together in the same bracket with a plus sign between them:
[Ctrl+Alt].
1. Numbered lists represent procedures with sequential steps.
♦ Bullet lists provide information, but do not involve sequential steps.
> Indicates consecutive selecting options (such as on a menu or
dialog box). For example, Start
>
Run means to open the Start
menu, and then select Run.
Indicates critical information.
Terminology Description
ATEN Controller,
controller
ATEN Controller or controller refers to all models of ATEN Control
Box and ATEN Control Pad.
ATEN Control Box,
Control Box
ATEN Control Box or Control Box refers to all models of ATEN
Control Box and Compact Control Box (Gen. 1 & 2).
Viewer A Viewer is a software control interface users customize to
control and operate devices in their control system. A Viewer is
configurable using ATEN Configurator and applied to a supported
control device, such as a mobile device, ATEN Keypad, or ATEN
Control Pad, for it to function.
Project A project is a configuration file, generated using ATEN
Configurator to specify settings of an ATEN Control System,
including one or multiple controllers, managed devices, and
control interfaces.
