Appendix
319
IR Learning
1 x IR Receiver LED
Reset Button
1 x Semi-recessed pushbutton
Power
Power Consumption AC 110 V : 4.7 W : 81 BTU
AC 220 V : 4.5 W : 81 BTU
Maximum Input Power Rating internal power: 100 - 240 V AC, 50 - 60 Hz
Environmental
Operating Temperature 0 – 50 ºC
Storage Temperature -20 – 60 ºC
Humidity 0 – 80% RH, Non-condensing
Physical Properties
Housing Metal
Weight 1.23 kg
Dimensions (L x W x H) 20.00 x 16.41 x 4.40 cm
Mobile Control License
No, of free licenses 2
Max. no. of licenses 32
Note: The ATEN Control Box comes with two free licenses which are stored
in the device itself. Each time a mobile device connects to an ATEN
Control Box for remote control, one license on the Control Box will be
occupied. To purchase and add additional licenses to your Control Box,
contact your local sales representative for more information.
