ATEN Control System User Manual
314
VK1100A
Memory
SDRAM 512 MB
Flash 8 GB
Interfaces
Serial 1 x Programmable bidirectional
RS-232/422/485 port (1 x 5-pole terminal block
connector, configurable via pin assignments)
Baud Rate: 300 to 115200 (default: 9600)
Data Bit: 8 (default) or 7
Stop Bit: 1 (default) or 2
Parity: None (default), Even, or Odd
Flow Control: None (default) or RTS/CTS
1 x bidirectional RS-232 port
(1 x 3-pole terminal block connector)
Baud Rate: 300 ~ 115200 (default: 9600)
Data Bit: 8 (default) or 7
Stop Bit: 1 (default) or 2
Parity: None (default), Even, or Odd
IR/Serial 2 x Programmable IR / Unidirectional
RS-232 Ports (2 x 2-Pole Terminal Block
Connectors)
IR:
Carrier Frequency: 10 ~ 455 kHz
Signal Level: TTL (0 ~ 5 V DC)
Serial:
Baud Rate: 300 ~ 115200 (default: 9600)
Data Bit: 8 (default) or 7
Stop Bit: 1 (default) or 2
Parity: None (default), Even, or Odd
Signal Level: TTL (0 ~ 5 V DC)
