ATEN Control System User Manual
248
Editing / Adding a New Device
To edit or add a device to My Library, do the following:
1. From the menu select File
→
Add New Device, or select a device from My
Library and click Edit.
2. Under General, use the drop-down menus or type in the Brand Name,
Category, Model and Version.
Note: The Category determines what buttons are auto generated when a
Viewer page is created for the device.
3. Use the History button to open the Version History editor and make notes
about the updates being made to the device configuration. You can create
and use different versions of the same device and track the changes. The
version history can be viewed and different versions selected from the
ATEN Configurator, under device Properties.
4. Check the hardware type and configure the device. ATEN database
generator supports serial, IR, digital output, relay, and Ethernet devices.
For more information about configuring each of these device type devices,
refer to the following sections.
Serial: See Serial Device, page 249.
IR: See IR Device, page 254.
Digital output: See Digital Output Device, page 257.
Relay: See Relay Device, page 258.
Ethernet: See Ethernet Device, page 259.
