ATEN Control System User Manual
150
Dialog
Click the Dialog tab to set up a confirmation message that displays in the
Viewer when the button is pressed.
Note: The Dialog settings are only available for Normal and Toggle
buttons.
Confirm the associated action with the following message when the
button is pressed – Click the check box to enable this feature.
Action – Select a button action (Toggle On or Toggle Off) to display
the confirmation message.
Content drop-down list – Select one of the following for
customization.
Background – Customize the wording for the confirmation
message. Type the message in the Name field and optionally
customize its font and style.
OK – Customize the wording on the button for carrying out the
associated action. Type in the Name field and optionally customize
its font and style.
Cancel – Customize the wording on the button for canceling the
associated action. Type in the Name field and optionally customize
its font and style.
Message
Click the Message tab to set up a progress message that displays while the
associated action is being carried out.
Note: The Message settings are only available for Normal and Toggle
buttons.
Confirm the associated action with the following message when the
button is pressed – Click the check box to enable this feature.
Action – Select a button action (Toggle On or Toggle Off) for
displaying the progress message.
Content drop-down list – Select one of the following for
customization.
Background – Configure the wording for the progress message.
Type the message in the Name field and optionally customize its
font and style.
Progress Bar – Configure the display duration (in seconds), font,
and color of the progress indicator.
