Samsung ITP5012L [103/164] Executive secretary hot line

Page 87

CONVENIENT FEATURES

5. Executive/Secretary Hot Line

Executive Status Display

Available only on phones with the Executive/Secretary Hot Line feature programmed, this feature is used to

display the in/out status of the executive or to conveniently set messages between the executive and

secretary.

An icon, indicating an executive or secretary, is displayed on the upper section of the LCD screen.

In the standby mode of the phone where the

Executive/Secretary Hot Line is enabled,

press the

[Screen]

button

until the Executive

Status screen is displayed.

Press the

[Select]

button corresponding to

the status of the executive. The current status

will be indicated by a grey filled status box.
