5. Choosing a Function
Because various features of this IP phone are displayed on the LCD screen, you can press the
[Select] button corresponding to the desired feature or dial the desired function code. Refer below.
The features available during a call are
displayed on the LCD screen.
Press the
[Select]
button of the
desired function.
To use the phone during standby mode, you can press the
[Screen]
button and
bring up the
Programmable Feature screen
or
Soft menu screen
or
Executive Status
Display
, and then press the [Select] button corresponding to the desired function.
!
The Executive Status Display screen will show up only on the phone where the
Executive/Secretary feature is set up.
- For the main screen, refer to the ‘Introduction of Main Screens’ section.
- If you want to use the function code to activate a function, refer to the next page.
- If you want to see additional menu pages or text on the LCD screen, scroll up and
down using the [Scroll] key, direction buttons or next page [Select] button.
NOTE
- Soft menu screen
- Programmable Feature Screen
