Samsung ITP5012L [20/164] Checking the parts in the package

Page 4 © SAMSUNG Electronics Co., Ltd.

PREPARATION

2. Checking the Parts in the Package

- Please contact your Authorised Samsung Reseller if any item above is missing

or damaged.

NOTE

Handset

LAN Cable

(for PC connection)

User GuidePhone Stand

ITP-5012L

Power Adaptor

(The view of power adaptor

and power input specification

may vary for each country.)
