Samsung ITP5012L [144/164] Off hook volume

Page 128

APPLICATION MENUS

Ringer Volume

Allows you to set the volume of the ringer.

Press the

button and use the direction button to select

[2. Ringer].

Then, press the

[Enter]

button.

There are 8 volume levels.

Press the

[▼Volume▲]

button to set

the volume.

Off-hook Volume

Allows you to set the volume of the Off-hook ring that that indicates a waiting call.

Press the

button and use the direction buttons to select

[3. OffHook Ring].

Then, press the

[Enter]

button.

There are 8 volume levels.

Press the

[▼Volume▲]

button to set

the volume.
