APPLICATION MENUS

BGM Volume

Allows you to set the Back Ground Music(BGM) volume when the BGM is set on the IP phone.

If BGM is not available on your phone refer to your System Administrator.

Press the

button and use the direction buttons to select

[6. BGM].

Then, press the

[Enter]

button.

There are 16 volume levels.

Press the

[▼Volume▲]

button to set

the volume.

Page Volume

Allows you to set the volume for received Page announcements.

Press the

button and use the direction buttons to select

[7. Page].

Then, press the

[Enter]

button.

There are 16 volume levels.

Press the

[▼Volume▲]

button to set

the volume.
