Samsung ITP5012L [98/164] Ohva block

Page 82

CONVENIENT FEATURES

OHVA Block

You can use the OHVA Block feature to reject all OHVA calls.

Press the

[Screen]

button until the Soft Menu

screen is displayed.

Press the

[Select]

button for

[OHVA BLOCK]

and then select [ON].

Press the [Select] button for [OFF] in

the [OHVA Block] menu to cancel OHVA Block.
