© SAMSUNG Electronics Co., Ltd.
Page 21
THING
S
YOU
S
HOULD KNOW
8. Volume Adjustment
[!Volume"] button is used for adjusting the volume of the handset, speaker, and ringer.
Adjusting Handset Volume
1.
During a call using the handset,
press the
[Volume
"
""
"
]
button to increase
the handset volume.
2.
Press the
[
!
!!
!
Volume
]
button to decrease
the handset volume.
Adjusting Speaker Volume
1.
During a call using the
[Speaker]
button,
press the
[Volume
"
""
"
]
button to increase
the speaker volume.
2.
Press the
[
!
!!
!
Volume
]
button to decrease
the speaker volume.
