Page 94

CONVENIENT FEATURES

Storing the Caller Number to a Speed Dial Number

The caller number can be stored in your personal speed dial number list.

Press the [Select] button for

[STORE]

displayed on the programmable features

screen during the call.

The personal speed dial number where

the caller number is saved is displayed

on the screen.

- Least Cost Routing(LCR) should be set accordingly to dial the saved caller number.

The CID cannot be saved without the LCR programmed on the OfficeServ system.

NOTE
