00.5
Model R 1150 R
Connection
12 Engine electrics
Starter motor to engine Nm 20
Starter cover to gearbox housing Nm 7
Positive lead to starter motor Nm 10
Alternator to alternator support cover Nm 20
Tensioning and retaining link to alternator Nm 21
Spacer to alternator Nm 21
Positive lead to alternator Nm 15
Belt pulley to alternator Nm 50
Belt pulley to crankshaft Nm 50
Poly-V belt preload Nm 8
Spark plug NGK BKR 7 EKC Nm 25
Model R 1150 R
Connection
13 Fuel preparation and control
Temperature sensor, oil, in crankcase Nm 25
Temperature sensor, air, in air-filter housing Nm 10
Model R 1150 R
Connection
16 Fuel tank and lines
Fuel tank to rear frame Nm 22
Fuel pump assembly to tank Nm 5
