00.23
Contents Page
00
Key to maintenance intervals ..............................................................................................27
Reading the BMW MoDiTeC fault code memory .......................................................27
(Inspections I, II, III and IV)
[Integral ABS] Performing bleed test with BMW MoDiTeC ..................................27
(Inspections I, II, III and IV)
Changing engine oil, replacing oil filter element ......................................................28
(Inspections I, II, III and IV)
Changing the transmission oil .............................................................................................29
(Inspections III and IV)
or at least every 2 years
Changing the oil in the rear wheel drive ........................................................................29
(Inspections I, III and IV)
Every 40,000 km (24,000 miles) or at the latest every 2 years
Replacing fuel filter ...................................................................................................................30
(Inspection III)
In normal operating conditions every 40,000 km (24,000 miles); if fuel quality is poor every
20,000 km (12,000 miles)
Checking battery fluid level and topping up if necessary; cleaning and
greasing the battery terminals
............................................................................................32
(Inspections III and IV)
Replacing intake air filter element ....................................................................................32
(Inspection III)
In very dirty and dusty operating conditions, replace every 10,000 km (6,000 miles) or even more
frequently if necessary
Replacing poly-V belt ...............................................................................................................33
(Inspection III)
every 60,000 km (36,000 miles)
[Without Integral ABS] Checking brake fluid level ...................................................34
(Inspections II and III)
Front brake .......................................................................................................................................34
Rear brake ........................................................................................................................................34
[Integral ABS] Checking brake fluid level .....................................................................35
(Inspections II and III)
Front brake .......................................................................................................................................35
Rear brake ........................................................................................................................................35
