Key to maintenance intervals
– BMW Inspection at 1,000 km
(approximately 600 miles) I
– BMW Service every 10,000 km
(approximately 6,000 miles) II
– BMW Inspection every 20,000 km
(approximately 12,000 miles) III
– BMW Annual Service IV
00 13 624
Reading the BMW MoDiTeC
fault code memory
(Inspections I, II, III and IV)
•
Remove front/rear seat.
•
Connect the BMW MoDiTeC to the diagnostic
connector.
•
Read all fault code memories.
•
Perform all requisite repair work.
[Integral ABS] Performing bleed test
with BMW MoDiTeC
(Inspections I, II, III and IV)
•
Remove front/rear seat.
•
Connect the BMW MoDiTeC to the diagnostic
connector.
d Warning:
Avoid rapid and forceful pumping of the brakes
when performing maintenance and repair work on
the BMW Integral ABS.
•
Perform bleed test.
•
Perform all requisite repair work.
