00.20
[Integral ABS] Performing bleed test
with BMW MoDiTeC
d Warning:
Self-diagnosis is not performed unless both brake
levers are in their fully released positions. Prior to
the conclusion of the self-diagnosis, only RESIDU-
AL BRAKE FUNCTION is available.
Performing BMW Integral ABS self-diagnosis:
•
Release the brake levers if necessary.
•
Switch on the ignition.
ABS warning light.............................flashes at 4 Hz
General warning lamp ........................is continuous
– Self-diagnosis is in progress
ABS warning light.............................flashes at 1 Hz
General warning lamp ...............................goes out
– Self-diagnosis successfully completed.
Performing a bleed test using the
BMW MoDiTeC:
•
Remove front/rear seat.
•
Connect the BMW MoDiTeC to the diagnostic
connector.
d Warning:
Avoid rapid and forceful pumping of the brakes
when performing maintenance and repair work on
the BMW Integral ABS.
•
Perform bleed test.
•
Perform all requisite repair work.
Performing BMW Integral ABS pull-away test:
•
The ABS warning light must go out when a
speed of 5 km/h (approx. 3 mph) is reached.
L Note:
The ABS warning light and the general warning light
must both be OFF after successful self-diagnosis
and the pull-away test.
Final inspection and function check
•
Clutch
•
Check gear shift action.
•
Handbrake and foot brake
•
Check lights and signalling equipment:
– Front and rear parking lights
– Instrument lighting
– Low and high headlight beams, headlight flasher
– Brake light (operate brake at front and rear)
– Turn signals left/right
– Hazard warning flashers
– Horn
– Indicator and warning lights
– Instruments
•
Where necessary, check function of optional ex-
tras:
•
If necessary, take the motorcycle for a test ride.
•
Confirm pre-delivery check in Service and Tech-
nical Booklet.
•
See “Checking motorcycle for damage” if defects
are found.
00 11 459
Final cleaning
•
Clean the motorcycle.
L Note:
Do not use a steam or high-pressure water jet. The
high steam or water pressure could damage seals,
the hydraulic system or electrical components.
