34.3
34
Technical Data R 1150 R
Brake fluid DOT 4
Front wheel
Colour of identification mark on brake cali-
pers/brake pads
green
Brake disc diameter mm (in) 320 (12.5987)
Brake disc thickness mm (in) 5.0 (0.1969)
Minimum thickness mm (in) 4.5 (0.1772)
Brake pad surface area cm
2
(sq in)
86 (13.33)
Piston diameter in brake caliper mm (in) 32/36 (1.2599/1.4173)
Piston diameter in handlebar lever cylinder mm (in) 16 (0.6299)
Sensor gap, front mm (in) 0.2...1.7 (0.0079...0.0670) (active sensor)
Brake pad lining Sintered metal
Minimum lining thickness, front mm (in) 1.0 (0.0393)
Rear wheel
Brake disc diameter mm (in) 276 (10.8663)
Brake disc thickness mm (in) 5.0 (0.1969)
Minimum thickness mm (in) 4.5 (0.1772)
Brake pad surface area cm
2
(sq in)
34 (5.27)
Piston diameter in brake caliper mm (in) 26/28 (1.0236/1.1023) with insulating piston
Piston diameter in foot brake cylinder mm (in) 12 (0.4724)
mm (in) [Integral ABS] 16 (0.6299)
Sensor gap, rear mm (in) 0.2…1.7 (0.0079...0.0670) (active sensor)
Brake pad lining Organic
Minimum lining thickness, rear mm (in) 1,0 (0.0393)
If the brake disc is visible through the bore in the
wheel-side brake pad, the brake lining is worn to
its minimum permissible thickness.
[ABS] Braking system BMW Integral ABS, partially integrated
