ALTERNATOR STARTER CLUTCH Check the starter reduction gear for wear or dam age Coat the readuction gear shaft with molybdenum oil solution Install the starter reduction gear and insert the shaft with the holed end facing out Apply locking agent to the cam chain guide bolt threads Install the cam chain guide arid tighten the bolt TORQUE 23 N m 2 3 kgf m 17 Ibf ft FLYWHEEL INSTALLATION Clean any oil from the tapered portion of the crank shaft and flywheel Install the groove woodruff key in the crankshaft key Apply oil to the needle bearing in the starter driven gear Install the flywheel on the crankshaft aligning the key way with the woodruff key and mesh the starter driven and ieduction gears If necessary remove the starter motor and check that the starter driven and reduction gears are meshed by turning the reduction gear The reduction gear should turn clockwise and not turn counterclockwise as viewed from starter motor side Apply oil to the flywheel bolt threads and seating surface and install the special washer and bolt Hold the flywheel with the special tool and tighten the bolt TOOL Flywheel holder 07725 0040000 or equivalent commercially available in U S A TORQUE 157 N m 16 0 kgf m 116 Ibf ft Install the left crankcase cover page 10 3 HI Install the flywheel see below Install the front cylinder cam sprockets page 8 20
