21D-Link DNS-722-4/DNS-726-4 User Manual
Section 3 - Configuration
When formatting of the drive completes, the NVR will prompt the user to restart. A restart countdown screen will appear,
and when the restart is complete, the login screen will appear:
Type admin for the username and
leave the password eld blank.
Note: After logging in to the NVR for the first time it is recommended to add a password to the admin account. (See page 40 for details.)
Press Restart to restart the NVR.
Click Login
