D-Link DNS-722-4 [28/88] Wizard
![D-Link DNS-722-4 [28/88] Wizard](/views2/1013364/page28/bg1c.png)
24D-Link DNS-722-4/DNS-726-4 User Manual
Section 3 - Configuration
Wizard
The NVR has a setup Wizard that allows you to quickly congure some of the basic device settings.
When running the NVR setup wizard, the welcome
screen details the ve steps of the wizard. Click
Next to continue.
It is recommended you set an admin password
here. Enter the new password and re-enter it for
conrmation. Click Next to continue.
Setup
