61D-Link DNS-722-4/DNS-726-4 User Manual
Section 3 - Configuration
Search the Recorded Video to Playback
Record Display Window:
Date Time Period:
Video Preview:
Display the available recorded video records.
Select the start and end points that indicate the time period you would like to view.
Check the Enable Preview option to view the selected video.
Users can refresh the Date Time Search Dialog Window or go to the previous or next recording date by pressing the
upper left corner buttons.
Refresh/
Previous/Next
Recording Date
Time Table
Show Records
Video Preview
Date Time Period
