20D-Link DNS-722-4/DNS-726-4 User Manual
Section 3 - Configuration
A warning message appears informing you that your
drives will be formatted and all data will be erased.
Click OK to continue.
When prompted to congure the Hard Drive Settings:
Configure Hard Drive
Select the type of hard drive conguration, Standard,
JBOD, RAID 0 or RAID 1.
Click Next to continue.
